Brand: Cepai
Packaging: BOX
Transportation: Ocean,Land,Air,Express
Port: shanghai,ningbo,huaian
Payment Type: L/C,T/T,D/P
Incoterm: FOB,CFR,CIF,EXW
The electric flanged Butterfly Valve is a butterfly valve controlled by an electric device, which realizes the control and adjustment of the fluid through the rotation of the valve disc driven by an electric motor. Compared with traditional manual butterfly valves, electric flanged butterfly valves have many product advantages:
Automatic control: The electric flanged butterfly valve can achieve remote control and automatic control without manual operation, improving work efficiency and safety.
Precise adjustment: The electric flanged butterfly valve uses a precision electric device, which can achieve accurate flow regulation to meet the needs of different working conditions.
Energy saving and environmental protection: The electric flanged butterfly valve is electrically driven, which can save energy and protect the environment compared with the traditional manual butterfly valve.
The advantages of electric three-Eccentric Butterfly Valve are outstanding. In addition, our company also produces Pneumatic Control Valve, Pneumatic Ball Valve, Pneumatic Butterfly Valve and other pneumatic valves. Please contact us if you need.
| Nominal circulation: | DN50-1300mm |
| Nominal pressure: | PN6, 10, 16，40，64, ANSI150~600; |
| Connection mode: | flange type, sandwich type |
| Body material: | WCB, CF8, CF8M, CF3M, etc |
| Packing: | PTFE, flexible graphite |
| Spool form: | three eccentric plate |
| Flow characteristics: | equal percentage, switch |
| Butterfly plate material: | 304, 316, 304L, 316L |
| Model: | three eccentric plate |
| Voltage: | equal percentage, switch |
| Ambient temperature: | -30-+70℃ |
| Control signal: | 4-20mADC (4-20mA signal feedback can be provided according to customer requirements) |
| Leakage: Metal seal: | according to ANSI B16.104 Class IV |
| Non-metal seal: | compliant with ANSI B16.104 Class VI |
Product Categories : Electric Butterfly Valve
