Brand: Cepai
Packaging: BOX
Transportation: Ocean,Land,Air,Express,Others
Port: Shanghai,Ningbo,Huaian
Payment Type: L/C,T/T
Incoterm: FOB,CFR,CIF,EXW
Pneumatic clip-on Triple Eccentric Butterfly Valve for a variety of fluid media, such as water, oil, gas and so on. It is widely used in petroleum, chemical, metallurgical, electric power, pharmaceutical and other industries in the fluid control system. The utility model has the advantages of simple structure, small volume, light weight, flexible operation and the like, and is an ideal control valve.
Three-eccentricity Butterfly Valve with pneumatic clamp has the following product features:
Clip-on connection: pneumatic clip-on Three Eccentric Butterfly Valve clip-on connection, you can easily install and remove the valve. The clamp connection can also ensure the sealing performance of the valve to prevent leakage.
Pneumatic control: the butterfly valve uses pneumatic device to control, can achieve remote control and automatic operation. Pneumatic control can improve the valve response speed and accuracy, reducing manual intervention.
Three-eccentricity structure: the butterfly valve uses three-eccentricity design, namely the valve shaft eccentricity, valve body eccentricity and seal face eccentricity. This structure can effectively reduce friction and wear, extend the service life of the valve.
We also produce other excellent products such as Pneumatic Control Valve, Pneumatic Ball Valve, Fluorine Lined Valve and so on. We also produce Flowmeter.You are welcome to consult.
| Nominal circulation: | DN50-1300mm |
| Nominal pressure: | PN6, 10, 16，40，64, ANSI150~600; |
| Connection mode: | flange type, sandwich type |
| Body material: | WCB, CF8, CF8M, CF3M, etc |
| Packing: | PTFE, flexible graphite |
| Spool form: | three eccentric plate |
| Flow characteristics: | equal percentage, switch |
| Butterfly plate material: | 304, 316, 304L, 316L |
| Model: | Piston actuator |
| Gas supply pressure: | 400 ~ 700kPa |
| Air source interface: | G1/8 ", G1/4 ", G3/8 ", G1/2" |
| Action form: | single action, double action |
| Leakage: Metal seal: | according to ANSI B16.104 Class IV |
| Non-metal seal: | compliant with ANSI B16.104 Class VI |
Product Categories : Pneumatic Butterfly Valve
