Pneumatic flanged Triple Eccentric Butterfly Valve is widely used in petroleum, chemical, metallurgical, electric power and other industries in the pipeline system, for regulating the flow rate and pressure medium. The utility model has the advantages of simple structure, convenient operation, reliable sealing, corrosion resistanc and the like, and is an ideal control valve.
Pneumatic flanged tri-eccentric butterfly valves have pneumatic actuators that control the opening and closing of the valve by Compressed air or other gases. By adjusting the gas pressure, the flow of the valve can be adjusted and remote control.
It is flanged for ease of installation and maintenance, with good sealing and flow regulation, its body and disc are usually made of corrosion-resistant materials,
such as stainless steel or cast iron, to adapt to different media and working environment.
The valves produced by our company are of good quality and are the reliable choice for many customers. Besides pneumatic valves, we also produce Electric Control Valve, Electric Ball Valve, Electric Butterfly Valve, etc. , you are welcome to come to buy.
| Nominal circulation: | DN50-1300mm |
| Nominal pressure: | PN6, 10, 16，40，64, ANSI150~600; |
| Connection mode: | flange type, sandwich type |
| Body material: | WCB, CF8, CF8M, CF3M, etc |
| Packing: | PTFE, flexible graphite |
| Spool form: | three eccentric plate |
| Flow characteristics: | equal percentage, switch |
| Butterfly plate material: | 304, 316, 304L, 316L |
| Model: | Piston actuator |
| Gas supply pressure: | 400 ~ 700kPa |
| Air source interface: | G1/8 ", G1/4 ", G3/8 ", G1/2" |
| Action form: | single action, double action |
| Leakage: Metal seal: | according to ANSI B16.104 Class IV |
| Non-metal seal: | compliant with ANSI B16.104 Class VI |
