The electric rubber-Lined Butterfly Valve is a valve controlled by an electric drive device and has a rubber-lined valve body lining. It uses advanced rubber lining technology to give the valve excellent corrosion resistance and sealing performance. This valve is suitable for the control and regulation of various corrosive media and is widely used in chemical, petroleum, electric power, metallurgy and other industries.

The main features of electric rubber-lined Butterfly Valve include the following aspects:

1. The valve body is lined with highly corrosion-resistant rubber lining materials, such as fluorine rubber, fluoroplastics, etc., which can effectively resist the erosion of various corrosive media and extend the service life of the valve.

2. The electric drive device adopts advanced motor and control system, which has the characteristics of quick response and precise control, and can realize remote control and automatic operation.

3. The valve has a simple structure, small size, light weight, easy installation, and has good fluid control performance and sealing performance.

4. The sealing surface of the valve adopts special design and processing technology to ensure the sealing reliability of the valve and reduce the risk of leakage.

5. The valve has various operating modes, and different driving modes such as manual, electric, and pneumatic can be selected according to needs.

In short, the electric rubber-lined butterfly valve is a valve product with reliable performance, corrosion resistance and reliable sealing, and is suitable for the control and regulation of various corrosive media.

Our company’s main products include Pneumatic Control Valve、Pneumatic Ball Valve、Electric Control Valve、 Fluorine Lined Valve、 Precession Vortex Flowmeter、 Throttling Gear.

VALVE BODY

Nominal diameter:	DN50-1000mm
Nominal pressure:	PN6, 10, 16, 25; ANSI 150LB
Flange connection:	sandwich type, flange type
Body material:	flange type
Gland form:	platen type
Body material:	WCB lined F46, CF8 lined F46, WCB lined PFA, CF8 lined PFA
Packing:	PTFE

Valve inner assembly

Spool form:	center line control plate
Flow characteristics:	equal percentage, switch
Internal materials:	WCB, CF8, CF8M with F46, PFA

Executive mechanism

Model:	Electric actuator
Voltage：	220V, 380V
Ambient temperature：	-30-+70℃
Control signal：	4-20mADC(4-20mA signal feedback can beprovided according to customer requirements)
